DN15 ball valve actuator motor, dC2.5V 1.8NM to open / close

Product description

The newly developed IP67 DC2.5V motor actuators for ball valve open or close, are available with different torque, speed reduction ratio and rotate speed. The actuator motor is well designed for the motorized ball valve open or close. The valve diameter range: DN15, DN20, DN25, DN32, DN40, up to DN80.The torque range from 1.8NM to 4.5 NM. The water flow control or heat control in water utility, HVAC, such as mini motorized ball valve , smart water meter with ball valve, zone valve, heat control, need be made through a mini motorized ball valve.

Technical data-Model K23
1. Voltage: DC3.6 V (Range: DC2.5 - 5 V, the higher the voltage, the larger torque, the shorter life span)
2. Current at idle: <25 mA @ 3.6V, 23ºC
3. Current with max loading: <450 mA (motor #300)
4. Torque: >2.5 NM (3500:1)
5. Open/close time: <13 S (3500:1)
6. Velocity reduction ratio: (3500:1)
7. Protection: IP67

Wiring definition

Production overview
