    Underfloor Heating Central Motorised Zone Valve PN16 Stainless Steel

    Ask Lasest Price
    Brand Name : Runpaq
    Model Number : 8013-DRF02
    Certification : NONE
    Price : USD3.59/piece (>1000pcs) / USD4.31/piece (50-1000 pcs)
    Payment Terms : L/C, T/T, D/A, D/P, Western Union
    Supply Ability : 200000 sets/month
    Delivery Time : 15-21 days
    • Product Details
    • Company Profile

    Underfloor Heating Central Motorised Zone Valve PN16 Stainless Steel

    Stainless steel motorized zone valve, motorized control valve for heating system

    Product Description
    The DC motorized control valve is a type of electric ball valve to control flow by either opening or closing an opening within a pipeline. When the valve is open, liquid is able to pass through freely. When the valve is closed, liquid flow is stopped and prevented from entering that section of pipe. It is essential that motorized control valves are ordered in the appropriate size for a system application, as this allows for them to create a reliable seal that liquids cannot penetrate.

    Application

    • HVAC system heating, ventilation, air conditioning
    • Heating system
    • Baseboard/radiant heating
    • Convectors
    • Fan coil units
    • Underfloor heating
    • Unit ventilators
    • VAV reheat

    Advantages

    • Sturday valve body with reasonable structure design, and best material to be used

    Underfloor Heating Central Motorised Zone Valve PN16 Stainless Steel

    NoNameMaterialAdvantage
    1.O-ring

    Import
    fluoro rubber (green)

    Resistance to high temperature, oil, corrosion, chemicals, Work temp.: —30℃+280℃.Quadruple seals, minimize the risk of leakage.
    2.DrainageDrain just in case leakage happens
    40-ringEPDM (red)Between nut and valve body, extra external leak proof, reduce the possibility of internal leak
    8.BallBrass or SS304Finely polished, rack nickel plating (not barrel plating), smooth surface, improved torque performance
    9.Water proof GAvoid water into housing, seal between valve body and valve housing

    Underfloor Heating Central Motorised Zone Valve PN16 Stainless Steel

    NoNameMaterialAdvantages
    5.Wall thickness2.0mm, PN20
    6.Teflon washerImport teflon

    1. Import teflon tube, numerical processing to perfectly match with ball surface
    2. Minimal deformation, polish surface, wearable

    70-ringEPDM

    1. Good elasticity, as buffer after Teflon washer to improve seal effect
    2. Reasonable structure design, ensures perfect holding margin
